    50 Amps Large Size 30mm Auto Blade Fuses UL Standard For Motorcycle

    Ask Lasest Price
    Brand Name : Yusheng
    Model Number : A,C,E Type
    Certification : UL
    Price : Negotiable
    Supply Ability : 1,000,000,000pcs per month
    Delivery Time : 5-7work days
    • Product Details
    • Company Profile

    50 Amps Large Size 30mm Auto Blade Fuses UL Standard For Motorcycle


    Large Size 30mm Auto Blade Fuses Rated 50A UL Standard Plug In Type Slow Blow


    Quick Detail:


    Product TypeFusing TypeOperating TemperatureMaterialColor
    Large Type (E Type)Slow Blow-40℃~+125℃

    PC resistance burnt material,

    Alloy terminal electrode


    Gray,Purple,Pink,Tan,

    Coffee,Red,Blue,Yellow,

    Natural,Green



    Description:

    Auto blade fuse is a kind of current fuse, when the circuit current exceeds 2 times of the rated current of the fuse, it will blow in a few seconds and play the role of circuit protection.It is often used to protect the overcurrent of automobile and industrial equipment. It is easy to identified and replaced. In the structure, the auto blade fuse adopts the plug-in design. It has an engineering plastic shell, which is wrapped with the melt structure made of zinc or copper. The metal melt and the pin are connected. Auto insert of the specifications of the fuse is commonly 2A to 40A, the amperes will be marked at the top of the fuse. Auto blade fuse international standard color: 2A - gray, 3A - purple, 4A - pink, 5A - Orange, 7.5A - Coffee, 10A - Red, 15A - Blue, 20A - Yellow, 25A - Transparent colorless, 30A - Green, 40A - Deep orange. According to the different color, can clearly distinguish the size of the different amperage. If the fuse is burnt out and the amperage is unrecognizable, it can also be judged by the color. Generally, auto blade fuse has three types of Mini(F Type),Medium(C Type) and Maximum(E Type).


    Specification:


    1. Electrical characteristics

    Test CurrentBlow Time
    20A30A40A50A60A70A80A
    135%1800180018001800180018001800
    60606060606060
    200%20304050606060
    468101544
    350%2456722
    0.711.41.720.20.2

    2.


    Dimensional Drawing

    Large Type(F Type)


    3. Reference Information

    TypeRated CurrentRated VoltageColorResistance Cold(mΩ)Minimum Melting HeatI2T(A2Sec)
    C2000301Z232Gray556.2
    C3000301Z332Purple349.4
    C4000301Z432Pink2417
    C5000301Z532Tan1825
    C7500301Z7.532Coffee1168
    C0010301Z1032Red7.393
    C0015301Z1532Blue4.5270
    C0020301Z2032Yellow3.2380
    C0025301Z2532Natural2.3625
    C0030301Z3032Green1.81130

    Applications:
    1. Auto Headlights
    2. Tail Lights
    3. Brake Lights
    4. Circuit Boards
    5. Sound equipment
    6. Little transformer

    7. Engine control unit

    8. Car horn

    9. Glass washer

    10. Window lifter

    11. airbag

    12. Electric seat

    13. Cigarette lighter


    Competitive Advantage:

    1. Small size,easy to install

    2. Sensitive reaction

    3. Completed certificates such as UL,VDE,SGS,etc and high quality available

    4. Industry standard color coding for quick identification of amp rating
    5. Tin-plated zinc terminals for corrosion resistance and enhanced conductivity
    6. UL Recognized for use in low voltage control circuits
    7. Wide operating temperature range -40℃~+125℃ meets the needs of extreme environments
    8. Lead free, halogen free and RoHS compliant
    9. Test points on specific part / package numbers may speed up circuit troubleshooting
    10. Readily identifiable and easily replaced
    11. Construction-Plastic housing with zinc fuse element and terminals.
