High Accuracy 10K 4*21 Flange Bullet NTC Temperature Sensor for
Microwave Oven
Quick Details:
| R value R25 | 1KΩ~1400KΩ (1K,2K,4.7K,5K,10K,15K,20K,30K,50K,100KΩ)etc. |
| B value R25/50 | 3270K~4650K(3270K,3380K,3470K,3550K,3700K,3950K,4200K,4650K) |
| R25 accuracy | ±1%,±2% |
| B value accuracy | ±1% |
| Temperature Range | -40~+300℃ |
| Shell size | Diameter:¢1.5~¢9mm;length:3mm~1000mm |
| Shell material | Stainless steel, copper, copper plated nickel, aluminum, ABS, PVC,
Epoxy |
| Wire | UL Series(such as UL1007),Teflon, PVC, XLPE, or Customized |
| Connector | Molex,JST,DuPont,CWB,CJT etc. |
| Drivepipe | Heat shrinkable tube;PVC tube,;glass fiber tube;teflon tube |
Description:
NTC Temperature Sensor is a detection element that feeds back the
results to the system. It is also called thermistor or probe. Its
principle is the resistance decreases rapidly when the temperature
rises. NTC(Negative Temperature CoeffiCient)refers to thermistor
phenomenon and material with negative temperature coefficient, and
the resistance decreases exponentially when the temperature rises. NTC temperature sensor is mainly used in household air conditioner,
auto air conditioner, refrigerator, stove, deep fryer, induction
cooker, soybean milk machine, electric oven, kitchen utensils and
appliances, floor heating,3d printers etc. temperature measurement and control.
Specifications:
1. Overall Dimensions(mm)
2. BOM
| Part Name | Material | QTY |
| NTC Housing | Φ 4*21 Probe+ Stainless steel insert | 1PCS |
| Base | Plastic | 1PCS |
| Resistance | R25=100KΩ±1% B25/50=3950K±1% | 1PCS |
| Lead Wire | UL3122 26# silicon braided wire | 300mm |
| Terminal | 110*0.5T lock catch | 1PCS |
| Terminal | 3.0*4.1 ring | 1 |
3. Electrical Specification:
| No. | Item | Sign | Test Condition | Min. | Normal value | Max. | Unit |
| 3-1. | Resistance at 25℃ | R25 | Ta=25±0.05℃ PT≦0.1mw | 99 | 100 | 10.1 | KΩ |
| 3-2. | B Value | B25/50 |  | 3910.5 | 3950 | 3989.5 | K |
| 3-3. | Dissipation factor(in air) | σ | Ta=25±0.05℃ | 3 | / | / | mW/℃ |
| 3-4. | Time constant(in water) | τ | 25℃→50℃ T1=25+(50-25)×63.2% =40.8℃ | / | / | 5 | Sec |
| 3-5. | Insulation resistance | / | 500VDC | 100 | / | / | MΩ |
| 3-6. | dielectric strength test | / | 1500V AC 0.5mA | 5 | / | / | S |
| 3-7. | Operating temperature range | / | / | -30 | / | 125 | ℃ |
4. TEMPERATURE VS RESISTANCE TABLE
Resistance 10K Ohms at 25deg. C Resistance Tolerance + / -1% B Value 3950K at 25/50 deg. C B Value Tolerance + / - 1% |
Temp. (deg. C) | Rmax (k Ohms) | Rnor (k Ohms) | Rmin (k Ohms) | Temp. (deg. C) | Rmax (k Ohms) | Rnor (k Ohms) | Rmin (k Ohms) |
| -30 | 1858.6927 | 1787.9797 | 1719.7849 | 136 | 2.5567 | 2.4391 | 2.3267 |
| -29 | 1744.9370 | 1679.6017 | 1616.5510 | 137 | 2.4928 | 2.3775 | 2.2674 |
| -28 | 1638.8912 | 1578.5061 | 1520.1940 | 138 | 2.4308 | 2.3178 | 2.2098 |
| -27 | 1539.9847 | 1484.1584 | 1430.2129 | 139 | 2.3705 | 2.2598 | 2.1540 |
| -26 | 1447.6929 | 1396.0662 | 1346.1459 | 140 | 2.3120 | 2.2034 | 2.0997 |
| -25 | 1361.5315 | 1313.7754 | 1267.5675 | 141 | 2.2552 | 2.1487 | 2.0471 |
| -24 | 1281.0560 | 1236.8685 | 1194.0856 | 142 | 2.2000 | 2.0956 | 1.9960 |
| -23 | 1205.8561 | 1164.9598 | 1125.3381 | 143 | 2.1463 | 2.0440 | 1.9463 |
| -22 | 1135.5532 | 1097.6941 | 1060.9911 | 144 | 2.0942 | 1.9939 | 1.8981 |
| -21 | 1069.7992 | 1034.7432 | 1000.7358 | 145 | 2.0436 | 1.9452 | 1.8513 |
| -20 | 1008.2715 | 975.8038 | 944.2871 | 146 | 1.9943 | 1.8978 | 1.8058 |
| -19 | 950.6732 | 920.5962 | 891.3817 | 147 | 1.9465 | 1.8518 | 1.7616 |
| -18 | 896.7294 | 868.8615 | 841.7754 | 148 | 1.9000 | 1.8071 | 1.7187 |
| -17 | 846.1864 | 820.3603 | 795.2428 | 149 | 1.8547 | 1.7637 | 1.6770 |
| -16 | 798.8093 | 774.8710 | 751.5750 | 150 | 1.8108 | 1.7215 | 1.6364 |
| -15 | 754.3810 | 732.1889 | 710.5786 | 151 | 1.7680 | 1.6804 | 1.5970 |
| -14 | 712.7005 | 692.1238 | 672.0741 | 152 | 1.7264 | 1.6405 | 1.5587 |
| -13 | 673.5814 | 654.4999 | 635.8954 | 153 | 1.6860 | 1.6017 | 1.5215 |
| -12 | 636.8513 | 619.1540 | 601.8883 | 154 | 1.6467 | 1.5640 | 1.4853 |
| -11 | 602.3502 | 585.9346 | 569.9095 | 155 | 1.6084 | 1.5273 | 1.4501 |
| -10 | 569.9298 | 554.7016 | 539.8262 | 156 | 1.5712 | 1.4915 | 1.4158 |
| -9 | 539.4526 | 525.3245 | 511.5153 | 157 | 1.5349 | 1.4568 | 1.3825 |
| -8 | 510.7906 | 497.6821 | 484.8615 | 158 | 1.4997 | 1.4230 | 1.3501 |
| -7 | 483.8254 | 471.6621 | 459.7586 | 159 | 1.4654 | 1.3901 | 1.3186 |
| -6 | 458.4467 | 447.1599 | 436.1073 | 160 | 1.4320 | 1.3582 | 1.2880 |
| -5 | 434.5519 | 424.0781 | 413.8153 | 161 | 1.3995 | 1.3270 | 1.2582 |
| -4 | 412.0460 | 402.3264 | 392.7968 | 162 | 1.3678 | 1.2967 | 1.2292 |
| -3 | 390.8401 | 381.8204 | 372.9716 | 163 | 1.3370 | 1.2672 | 1.2009 |
| -2 | 370.8519 | 362.4818 | 354.2653 | 164 | 1.3070 | 1.2385 | 1.1734 |
| -1 | 352.0045 | 344.2375 | 336.6083 | 165 | 1.2778 | 1.2106 | 1.1467 |
| 0 | 334.2264 | 327.0195 | 319.9360 | 166 | 1.2494 | 1.1833 | 1.1207 |
| 1 | 317.4508 | 310.7640 | 304.1877 | 167 | 1.2217 | 1.1568 | 1.0953 |
| 2 | 301.6157 | 295.4121 | 289.3072 | 168 | 1.1947 | 1.1310 | 1.0706 |
| 3 | 286.6631 | 280.9084 | 275.2418 | 169 | 1.1684 | 1.1059 | 1.0466 |
| 4 | 272.5389 | 267.2014 | 261.9423 | 170 | 1.1428 | 1.0814 | 1.0232 |
| 5 | 259.1926 | 254.2428 | 249.3626 | 171 | 1.1179 | 1.0576 | 1.0004 |
| 6 | 246.5770 | 241.9877 | 237.4601 | 172 | 1.0935 | 1.0343 | 0.9782 |
| 7 | 234.6482 | 230.3940 | 226.1943 | 173 | 1.0698 | 1.0117 | 0.9566 |
| 8 | 223.3650 | 219.4224 | 215.5278 | 174 | 1.0467 | 0.9896 | 0.9355 |
| 9 | 212.6890 | 209.0361 | 205.4255 | 175 | 1.0242 | 0.9681 | 0.9150 |
| 10 | 202.5840 | 199.2007 | 195.8544 | 176 | 1.0023 | 0.9472 | 0.8950 |
| 11 | 193.0167 | 189.8841 | 186.7836 | 177 | 0.9809 | 0.9268 | 0.8756 |
| 12 | 183.9552 | 181.0559 | 178.1844 | 178 | 0.9601 | 0.9069 | 0.8566 |
| 13 | 175.3704 | 172.6881 | 170.0298 | 179 | 0.9397 | 0.8875 | 0.8381 |
| 14 | 167.2345 | 164.7540 | 162.2942 | 180 | 0.9199 | 0.8686 | 0.8200 |
| 15 | 159.5216 | 157.2290 | 154.9539 | 181 | 0.9006 | 0.8501 | 0.8024 |
| 16 | 152.2075 | 150.0898 | 147.9867 | 182 | 0.8817 | 0.8321 | 0.7853 |
| 17 | 145.2694 | 143.3144 | 141.3716 | 183 | 0.8633 | 0.8146 | 0.7686 |
| 18 | 138.6861 | 136.8825 | 135.0889 | 184 | 0.8454 | 0.7975 | 0.7523 |
| 19 | 132.4375 | 130.7749 | 129.1202 | 185 | 0.8279 | 0.7808 | 0.7364 |
| 20 | 126.5049 | 124.9734 | 123.4482 | 186 | 0.8108 | 0.7646 | 0.7209 |
| 21 | 120.8705 | 119.4612 | 118.0564 | 187 | 0.7941 | 0.7487 | 0.7058 |
| 22 | 115.5180 | 114.2223 | 112.9298 | 188 | 0.7779 | 0.7332 | 0.6911 |
| 23 | 110.4316 | 109.2417 | 108.0537 | 189 | 0.7620 | 0.7181 | 0.6767 |
| 24 | 105.5969 | 104.5053 | 103.4147 | 190 | 0.7465 | 0.7034 | 0.6627 |
| 25 | 101.0000 | 100.0000 | 99.0000 | 191 | 0.7314 | 0.6890 | 0.6490 |
| 26 | 96.7127 | 95.7132 | 94.7146 | 192 | 0.7166 | 0.6749 | 0.6356 |
| 27 | 92.6306 | 91.6333 | 90.6378 | 193 | 0.7022 | 0.6612 | 0.6226 |
| 28 | 88.7426 | 87.7492 | 86.7583 | 194 | 0.6882 | 0.6479 | 0.6099 |
| 29 | 85.0386 | 84.0505 | 83.0655 | 195 | 0.6744 | 0.6348 | 0.5975 |
| 30 | 81.5090 | 80.5274 | 79.5497 | 196 | 0.6610 | 0.6221 | 0.5853 |
| 31 | 78.1446 | 77.1707 | 76.2012 | 197 | 0.6479 | 0.6096 | 0.5735 |
| 32 | 74.9370 | 73.9717 | 73.0115 | 198 | 0.6351 | 0.5975 | 0.5620 |
| 33 | 71.8779 | 70.9222 | 69.9721 | 199 | 0.6227 | 0.5856 | 0.5507 |
| 34 | 68.9598 | 68.0144 | 67.0752 | 200 | 0.6105 | 0.5740 | 0.5397 |
| 35 | 66.1755 | 65.2411 | 64.3134 | 201 | 0.5985 | 0.5627 | 0.5290 |
| 36 | 63.5182 | 62.5954 | 61.6798 | 202 | 0.5869 | 0.5517 | 0.5185 |
| 37 | 60.9814 | 60.0707 | 59.1677 | 203 | 0.5755 | 0.5409 | 0.5082 |
| 38 | 58.5591 | 57.6610 | 56.7710 | 204 | 0.5644 | 0.5303 | 0.4982 |
| 39 | 56.2456 | 55.3604 | 54.4837 | 205 | 0.5536 | 0.5200 | 0.4884 |
| 40 | 54.0355 | 53.1635 | 52.3004 | 206 | 0.5430 | 0.5099 | 0.4789 |
| 41 | 51.9235 | 51.0651 | 50.2158 | 207 | 0.5326 | 0.5001 | 0.4696 |
| 42 | 49.9049 | 49.0602 | 48.2250 | 208 | 0.5225 | 0.4905 | 0.4604 |
| 43 | 47.9752 | 47.1443 | 46.3232 | 209 | 0.5126 | 0.4811 | 0.4515 |
| 44 | 46.1298 | 45.3130 | 44.5062 | 210 | 0.5029 | 0.4719 | 0.4428 |
| 45 | 44.3649 | 43.5621 | 42.7696 | 211 | 0.4934 | 0.4630 | 0.4343 |
| 46 | 42.6764 | 41.8878 | 41.1096 | 212 | 0.4842 | 0.4542 | 0.4260 |
| 47 | 41.0607 | 40.2862 | 39.5224 | 213 | 0.4751 | 0.4456 | 0.4179 |
| 48 | 39.5143 | 38.7539 | 38.0044 | 214 | 0.4663 | 0.4372 | 0.4100 |
| 49 | 38.0339 | 37.2876 | 36.5524 | 215 | 0.4576 | 0.4290 | 0.4022 |
| 50 | 36.6163 | 35.8842 | 35.1631 | 216 | 0.4492 | 0.4210 | 0.3946 |
| 51 | 35.2587 | 34.5405 | 33.8335 | 217 | 0.4409 | 0.4132 | 0.3872 |
| 52 | 33.9582 | 33.2538 | 32.5608 | 218 | 0.4328 | 0.4055 | 0.3800 |
| 53 | 32.7121 | 32.0214 | 31.3423 | 219 | 0.4249 | 0.3980 | 0.3729 |
| 54 | 31.5178 | 30.8408 | 30.1754 | 220 | 0.4171 | 0.3907 | 0.3660 |
| 55 | 30.3731 | 29.7096 | 29.0576 | 221 | 0.4096 | 0.3836 | 0.3592 |
| 56 | 29.2755 | 28.6253 | 27.9868 | 222 | 0.4021 | 0.3765 | 0.3525 |
| 57 | 28.2230 | 27.5860 | 26.9607 | 223 | 0.3949 | 0.3697 | 0.3461 |
| 58 | 27.2135 | 26.5895 | 25.9772 | 224 | 0.3878 | 0.3630 | 0.3397 |
| 59 | 26.2450 | 25.6338 | 25.0343 | 225 | 0.3809 | 0.3564 | 0.3335 |
| 60 | 25.3156 | 24.7171 | 24.1303 | 226 | 0.3741 | 0.3500 | 0.3274 |
| 61 | 24.4237 | 23.8376 | 23.2633 | 227 | 0.3674 | 0.3437 | 0.3215 |
| 62 | 23.5675 | 22.9937 | 22.4315 | 228 | 0.3609 | 0.3376 | 0.3157 |
| 63 | 22.7454 | 22.1836 | 21.6336 | 229 | 0.3545 | 0.3315 | 0.3100 |
| 64 | 21.9560 | 21.4061 | 20.8678 | 230 | 0.3483 | 0.3257 | 0.3045 |
| 65 | 21.1977 | 20.6594 | 20.1328 | 231 | 0.3422 | 0.3199 | 0.2990 |
| 66 | 20.4692 | 19.9424 | 19.4272 | 232 | 0.3362 | 0.3142 | 0.2937 |
| 67 | 19.7693 | 19.2537 | 18.7497 | 233 | 0.3304 | 0.3087 | 0.2885 |
| 68 | 19.0966 | 18.5920 | 18.0990 | 234 | 0.3246 | 0.3033 | 0.2834 |
| 69 | 18.4499 | 17.9562 | 17.4740 | 235 | 0.3190 | 0.2980 | 0.2784 |
| 70 | 17.8282 | 17.3452 | 16.8735 | 236 | 0.3135 | 0.2928 | 0.2735 |
| 71 | 17.2304 | 16.7578 | 16.2965 | 237 | 0.3081 | 0.2878 | 0.2687 |
| 72 | 16.6554 | 16.1930 | 15.7419 | 238 | 0.3029 | 0.2828 | 0.2640 |
| 73 | 16.1023 | 15.6499 | 15.2087 | 239 | 0.2977 | 0.2779 | 0.2594 |
| 74 | 15.5702 | 15.1276 | 14.6961 | 240 | 0.2927 | 0.2732 | 0.2549 |
| 75 | 15.0581 | 14.6251 | 14.2032 | 241 | 0.2877 | 0.2685 | 0.2505 |
| 76 | 14.5652 | 14.1417 | 13.7291 | 242 | 0.2829 | 0.2639 | 0.2462 |
| 77 | 14.0907 | 13.6764 | 13.2729 | 243 | 0.2781 | 0.2594 | 0.2420 |
| 78 | 13.6339 | 13.2286 | 12.8341 | 244 | 0.2734 | 0.2550 | 0.2379 |
| 79 | 13.1940 | 12.7976 | 12.4118 | 245 | 0.2689 | 0.2507 | 0.2338 |
| 80 | 12.7703 | 12.3825 | 12.0053 | 246 | 0.2644 | 0.2465 | 0.2298 |
| 81 | 12.3622 | 11.9828 | 11.6139 | 247 | 0.2600 | 0.2424 | 0.2259 |
| 82 | 11.9689 | 11.5978 | 11.2372 | 248 | 0.2557 | 0.2384 | 0.2221 |
| 83 | 11.5900 | 11.2270 | 10.8743 | 249 | 0.2515 | 0.2344 | 0.2184 |
| 84 | 11.2247 | 10.8697 | 10.5248 | 250 | 0.2474 | 0.2305 | 0.2148 |
| 85 | 10.8727 | 10.5254 | 10.1881 | 251 | 0.2433 | 0.2267 | 0.2112 |
| 86 | 10.5332 | 10.1935 | 9.8637 | 252 | 0.2394 | 0.2230 | 0.2077 |
| 87 | 10.2059 | 9.8736 | 9.5511 | 253 | 0.2355 | 0.2193 | 0.2042 |
| 88 | 9.8902 | 9.5652 | 9.2499 | 254 | 0.2317 | 0.2157 | 0.2009 |
| 89 | 9.5858 | 9.2678 | 8.9594 | 255 | 0.2279 | 0.2122 | 0.1976 |
| 90 | 9.2920 | 8.9809 | 8.6794 | 256 | 0.2243 | 0.2088 | 0.1943 |
| 91 | 9.0085 | 8.7042 | 8.4094 | 257 | 0.2207 | 0.2054 | 0.1911 |
| 92 | 8.7350 | 8.4373 | 8.1489 | 258 | 0.2172 | 0.2021 | 0.1880 |
| 93 | 8.4710 | 8.1797 | 7.8977 | 259 | 0.2137 | 0.1988 | 0.1850 |
| 94 | 8.2161 | 7.9312 | 7.6554 | 260 | 0.2103 | 0.1957 | 0.1820 |
| 95 | 7.9700 | 7.6912 | 7.4215 | 261 | 0.2070 | 0.1925 | 0.1791 |
| 96 | 7.7324 | 7.4596 | 7.1958 | 262 | 0.2037 | 0.1895 | 0.1762 |
| 97 | 7.5029 | 7.2360 | 6.9780 | 263 | 0.2005 | 0.1865 | 0.1734 |
| 98 | 7.2812 | 7.0201 | 6.7677 | 264 | 0.1974 | 0.1835 | 0.1706 |
| 99 | 7.0670 | 6.8115 | 6.5647 | 265 | 0.1943 | 0.1806 | 0.1679 |
| 100 | 6.8601 | 6.6101 | 6.3686 | 266 | 0.1913 | 0.1778 | 0.1652 |
| 101 | 6.6601 | 6.4155 | 6.1793 | 267 | 0.1884 | 0.1750 | 0.1626 |
| 102 | 6.4668 | 6.2274 | 5.9964 | 268 | 0.1855 | 0.1723 | 0.1601 |
| 103 | 6.2799 | 6.0457 | 5.8197 | 269 | 0.1826 | 0.1696 | 0.1575 |
| 104 | 6.0993 | 5.8701 | 5.6489 | 270 | 0.1798 | 0.1670 | 0.1551 |
| 105 | 5.9246 | 5.7003 | 5.4839 | 271 | 0.1771 | 0.1644 | 0.1527 |
| 106 | 5.7557 | 5.5362 | 5.3245 | 272 | 0.1744 | 0.1619 | 0.1503 |
| 107 | 5.5923 | 5.3775 | 5.1703 | 273 | 0.1717 | 0.1594 | 0.1480 |
| 108 | 5.4343 | 5.2240 | 5.0213 | 274 | 0.1691 | 0.1570 | 0.1457 |
| 109 | 5.2814 | 5.0755 | 4.8772 | 275 | 0.1666 | 0.1546 | 0.1435 |
| 110 | 5.1334 | 4.9319 | 4.7379 | 276 | 0.1641 | 0.1522 | 0.1413 |
| 111 | 4.9903 | 4.7930 | 4.6031 | 277 | 0.1616 | 0.1499 | 0.1391 |
| 112 | 4.8517 | 4.6586 | 4.4727 | 278 | 0.1592 | 0.1477 | 0.1370 |
| 113 | 4.7175 | 4.5285 | 4.3466 | 279 | 0.1568 | 0.1455 | 0.1349 |
| 114 | 4.5877 | 4.4026 | 4.2245 | 280 | 0.1545 | 0.1433 | 0.1329 |
| 115 | 4.4619 | 4.2807 | 4.1064 | 281 | 0.1522 | 0.1412 | 0.1309 |
| 116 | 4.3401 | 4.1627 | 3.9921 | 282 | 0.1500 | 0.1391 | 0.1289 |
| 117 | 4.2222 | 4.0484 | 3.8815 | 283 | 0.1478 | 0.1370 | 0.1270 |
| 118 | 4.1079 | 3.9378 | 3.7743 | 284 | 0.1456 | 0.1350 | 0.1251 |
| 119 | 3.9972 | 3.8306 | 3.6706 | 285 | 0.1435 | 0.1330 | 0.1232 |
| 120 | 3.8900 | 3.7268 | 3.5702 | 286 | 0.1414 | 0.1310 | 0.1214 |
| 121 | 3.7861 | 3.6263 | 3.4729 | 287 | 0.1394 | 0.1291 | 0.1196 |
| 122 | 3.6854 | 3.5289 | 3.3787 | 288 | 0.1374 | 0.1272 | 0.1179 |
| 123 | 3.5877 | 3.4345 | 3.2874 | 289 | 0.1354 | 0.1254 | 0.1161 |
| 124 | 3.4931 | 3.3430 | 3.1990 | 290 | 0.1335 | 0.1236 | 0.1144 |
| 125 | 3.4014 | 3.2543 | 3.1133 | 291 | 0.1316 | 0.1218 | 0.1128 |
| 126 | 3.3124 | 3.1683 | 3.0302 | 292 | 0.1297 | 0.1201 | 0.1111 |
| 127 | 3.2261 | 3.0850 | 2.9497 | 293 | 0.1279 | 0.1183 | 0.1095 |
| 128 | 3.1424 | 3.0042 | 2.8717 | 294 | 0.1260 | 0.1166 | 0.1079 |
| 129 | 3.0613 | 2.9258 | 2.7960 | 295 | 0.1243 | 0.1150 | 0.1064 |
| 130 | 2.9825 | 2.8498 | 2.7227 | 296 | 0.1225 | 0.1134 | 0.1049 |
| 131 | 2.9061 | 2.7761 | 2.6515 | 297 | 0.1208 | 0.1118 | 0.1034 |
| 132 | 2.8320 | 2.7045 | 2.5826 | 298 | 0.1191 | 0.1102 | 0.1019 |
| 133 | 2.7601 | 2.6352 | 2.5157 | 299 | 0.1175 | 0.1086 | 0.1005 |
| 134 | 2.6902 | 2.5678 | 2.4507 | 300 | 0.1158 | 0.1071 | 0.0990 |
| 135 | 2.6225 | .5025 | 2.3878 | | | | |
Application:
1. Rice cooker, Wall hung gas bolier, Household air conditioner,
2. Automobile air conditioners, refrigerators, freezers,
3. Water heaters, water dispensers, heaters,
4. Dishwashers, disinfection cabinet, washing machines,
5. Dryers and low temperature in the drying oven,
6. Incubator temperature measurement and control.
Advantages:
1. High stability constant (B value), small remain resistance.
2. Long service life, thoughtful service.
3. Extensive operating range.
4. Good coherence and interchange capability.
5. High precision of resistance and B-value.
6. Good quality of insulation and packing.
7. Can accept customized specification.
8. Temperature range: -40-150C.
Tag:
Resistance Sensor, Thermistor, Temperature Transducer, Temperature
Probe
